Chirascan™ V100

Ready to run –

when sensitivity and accuracy are key

Suitable for studying chiral molecules of all types and sizes, the sensitivity and accuracy of a Chirascan V100 CD spectrometer ensure that researchers get the most from every CD analysis, generating high quality data that contribute to a deeper understanding of biomolecular characteristics, mechanisms and interactions.

More than α-helix and β-sheet -
determine structural and thermodynamic properties

  • Achieve highest sensitivity and accuracy
  • Gain insight and detect changes in secondary and tertiary structure
  • Determine response to thermal or chemical change
  • Study folding and unfolding mechanisms
  • Expand capabilities with dedicated Chirascan accessories
TOP

Ready to run

Chirascan systems are supplied with the features and accessories required for acquisition of high quality data from ‘day one’.

MOLECULAR SIEVE,
ACTIVATED CHARCOAL FILTER

  • Removes common gas impurities

ACTIVE NITROGEN
MANAGEMENT SYSTEM

  • Regulates purge gas consumption
  • Software-controlled

AIR-COOLED XENON LAMP

  • Software-controlled
  • Up-time recorded

MONOCHROMATOR

  • Produces horizontally, linearly polarized ­monochromatic light
  • Dual polarizing prisms maximize light ­throughput

PHOTOELASTIC MODULATOR

  • Converts horizontally polarized light to ­circularly polarized light. ­Alternates between left- and right-handed circular polarized light

TEMPERATURE-CONTROLLED
SAMPLE CHAMBER

  • Consistent analytical conditions
  • Continuous temperature ramps
  • Temperature measured directly in sample

WATER CIRCULATOR

  • Dissipates heat from sample chamber and sample storage Peltiers

AVALANCHE PHOTODIODE DETECTOR

  • Highest sensitivity (high signal: noise)

OPTICS-BASED, MULTIWAVE­LENGTH CALIBRATION

  • For CD accuracy

CUVETTES AND HOLDERS

  • Selected for far- and near-UV CD analysis of biomolecules (single sample mode)
TOP

Control and analysis software

  • Easily defined run parameters and store routine protocols
  • Saves time with scheduled start-up/shutdown of lamp and N2 supply
  • Fail-safe lamp switch-off if N2 flow drops
  • Ensures O2-free conditions with N2 purge
  • Recognizes flow cell to select optimal run/wash/dry protocol

GLOBAL THERMODYNAMIC ANALYSIS

  • Derive melting points and enthalpies from multiwavelength, thermal ­denaturation ­experiments
